The linkage line is composed of HQCLA series vertical ultrasonic bottle washer, HSDH series hot air circulation sterilization tunnel, HKGZ series oral liquid filling and capping machine, which can be used in combination or single machine. The linkage line can complete the processes of water spray filling, ultrasonic cleaning and flushing (inside and outside), CA flushing (inside and outside), preheating, dry sterilization to remove heat sources, cooling, filling, sealing, capping and other processes.

The production line can meet the process requirements of deheating, filling and capping of various oral liquid bottles, infusion bottles and syrup bottles in the size range from 5-30ml, 50-500ml.

Vertical ultrasonic cleaning machine adopts ultrasonic rough cleaning, circulating water, WFl and clean compressed air alternately spray to clean the container. Cleaning clarity and visible substance detection effect is ideal: it is the most popular cleaning machine in the world today.

The filling and capping machine adopts large wheel drive, reciprocating tracking filling, single or three knife form, high capping rate, is the most popular filling and capping machine in the world today.
